Canon imageFORCE 4025

Detaylı özellikler

Ana Ünite

• Makine Tipi
  A3 Tek Renkli Çok Fonksiyonlu
• Temel Fonksiyonlar
  Yazdırma, Kopyalama, Tarama, Gönderme ve İsteğe Bağlı Faks
• İşlemci Hızı
  1.6GHz Çift Çekirdekli İşlemci
• Kontrol Paneli
  7 inç TFT LCD WVGA Renkli Dokunmatik Panel
• Hafıza
  Standart: 3.0 GB RAM
• Depolamak
  Standart: 64 GB eMMC
  İsteğe bağlı: 256 GB SSD
• Arayüz Bağlantısı
  AĞ
  Standardı: 1000Base-T/100Base-TX/10Base-T, Kablosuz LAN (IEEE 802.11 b/g/n)

  DİĞERLERİ
  Standardı: USB 2.0 (Ana Bilgisayar) x2, USB 2.0 (Cihaz) x1
  İsteğe bağlı: Kopyalama Kontrol Arayüzü
• Kağıt Besleme Kapasitesi (A4, 80 gsm)
  Standart: 1.200 yaprak
  100 yaprak: Çok amaçlı tepsi x 1
  550 yaprak: Standart kaset x 2
  Maksimum: 2.300 yaprak (Kaset Besleme Ünitesi-BB1 ile)
• Kağıt Çıkış Kapasitesi (A4, 80 gsm)
  Standart: 250 sayfa
  Maksimum: 645 sayfa (İç Sonlandırıcı-N1 ve Fotokopi Tepsisi-T2 ile birlikte)
• Bitirme Yetenekleri
  Harmanlama, Gruplama, Ofset, Zımbalama, Delgeç, Çevre Dostu Zımbalama, İsteğe Bağlı Zımbalama

  * Bağlanan seçeneklere bağlı olarak sonlandırma özellikleri değişiklik gösterebilir.
• Desteklenen Medya Türleri
  Çok amaçlı tepsi:
  İnce, Düz, Geri Dönüştürülmüş, Renkli, Kalın, Kaplamalı*,
  İzleme, Bond, Şeffaf, Etiketler, Önceden Delikli, Antetli Kağıt, Zarf

  * 257-300 g/m² için Medya Ayarlama Kiti-A1 gereklidir

  . Üst Kaset:
  İnce, Düz, Geri Dönüştürülmüş, Renkli, Kalın, Bond, Şeffaf, Önceden Delikli, Antetli Kağıt, Zarf

  Alt Kaset:
  İnce, Düz, Geri Dönüştürülmüş, Renkli, Kalın, Bond, Şeffaf, Önceden Delikli, Antetli Kağıt, Zarf*

  * Zarf Besleyici Eklentisi A (standart) gereklidir.
• Desteklenen Medya Boyutları
  Multi-purpose tray:
  Standard size: SRA3, A3, A4, A4R, A5, A5R,
  A6R, B4, B5, B5R
  Custom size: 98.4 x 139.7 mm to 320.0 x 457.2 mm
  Free size: 100.0 x 148.0 mm to 304.8 x 457.2 mm
  Envelopes: COM10 No.10, Monarch, ISO-C5, DL
  Envelope custom size: 98.0 x 98.0 mm to 320.0 x 457.2 mm

  Upper Cassette:
  Standard size: A4, A5, A5R, A6R, B5
  Custom Size: 105.0 x 148.0 mm to 297.0 x 215.9 mm
  Envelopes: ISO-C5

  Lower Cassette:
  Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
  Custom Size: 105.0 x 148.0 mm to 304.8 x 457.2 mm
  Envelopes*: COM10 No.10, Monarch, DL

  * Envelope Attachment A (standard) is required.
• Supported Media Weights
  Multi-purpose tray: 52 to 300 gsm (Only 60 to 300 gsm supported with Media Adjustment Kit-A1*)

  * Media Adjustment Kit-A1 is required for Coated (257-300gsm)

  Upper/Lower Cassette:
  52 to 256 gsm
  Duplex:
  52 to 220 gsm
• Warm-up Time
  4 Seconds
  From Sleep Mode: 10 seconds
• Dimensions (W x D x H)
  565 x 712 x 862 mm
• Installation Space (W x D)
  Basic：
  978 x 1,141 mm (right door & multi-purpose tray opened + paper cassette opened)

  Fully Configured：
  1,285 x 1,141 mm (with Inner Finisher tray max extended + Copy Tray-T2 max extended + paper cassette opened）
• Weight
  Approx. 69 kg

Print Specifications

• Print Speed
  imageFORCE 4045:
  1-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 25 ppm (A4R)
  2-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 25 ppm (A4R)

  imageFORCE 4030:
  1-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)
  2-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)

  imageFORCE 4025:
  1-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)
  2-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)
• Print Resolution (dpi)
  4,800 x 2,400
• Page Description Languages
  Standard: UFRII, PCL6/PCL5
  Optional: Adobe® PostScript®3TM
• Mobile / Cloud Printing
  AirPrint, Mopria, IPP Everywhere, Canon PRINT, uniFLOW Online and Universal Print

  A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
  Please contact your sales representative for further information.
• OS Standard Printing
  Android, Windows® 10/11, Chrome OS, macOS (11.2.2 or later), iOS (15.2 or later), iPadOS
• Fonts
  PS fonts: 136 Roman
  PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T*1 (Japanese, Korean, Simplified and Traditional Chinese) , Barcode fonts*2

  *1 Optional PCL International Font Set-A1 is required.
  *2 Optional Barcode Printing Kit-D1 is required.
• Print Features
  Secure Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/ Orientations, Toner Reduction, Poster Printing, Forced hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer
• Operating Systems
  UFR II: Windows® 10/11/Server2016/Server2019/Server2022/Server2025, macOS(11.7 or later)
  PCL: Windows® 10/11/Server2016/Server2019/Server2022/Server2025
  PS: Windows® 10/11/Server2016/Server2019/Server2022/Server2025, macOS(11.7 or later)
  PPD: Windows® 10/11, macOS(11.7 or later)

  *As of Mar. 2026

Copy Specifications

• Copy Speed
  imageFORCE 4045:
  1-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 25 ppm (A4R)
  2-sided: Up to 45 ppm (A4), Up to 22 ppm (A3), Up to 25 ppm (A4R)

  imageFORCE 4030:
  1-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)
  2-sided: Up to 30 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)

  imageFORCE 4025:
  1-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)
  2-sided: Up to 25 ppm (A4), Up to 15 ppm (A3), Up to 15 ppm (A4R)
• First-Copy-Out Time
  imageFORCE 4045: 5.3 seconds
  imageFORCE 4030: 7.0 seconds
  imageFORCE 4025: 7.0 seconds
• Copy Resolution (dpi)
  600 x 600
• Multiple Copies
  Up to 9,999 copies
• Magnification
  Variable zoom: 25% to 400% (1% Increments)
• Copy Features
  Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Sort, Job Build, N on 1, Different Size Originals, Sharpness, Erase Frame, Gutter, Copy ID Card, Skip Blank Pages, Free Size Original, Reserved copy, Copy Sample

Scan Specifications

• Type
  imageFORCE 4045:
  Standard: Color Scanner, Single Pass DADF-F1* [2-sided to 2-sided]

  imageFORCE 4030/4025:
  Standard: Color Scanner, Single Pass DADF-G1* [2-sided to 2-sided]

  * Multi-Sheet Feed Detection is supported as an option.

  DADF: Duplexing Automatic Document Feeder
• Pull Scan Specifications
  Colour Network ScanGear2. For both TWAIN and WIA
  Supported OS: Windows®11/Server 2016/Server 2019/Server 2022/Server 2025*

  *As of Mar. 2026
• Scan Resolution (dpi)
  600 x 600
• Document Feeder Paper Capacity (80 gsm)
  up to 100 sheets
• Acceptable Originals/Weights
  Document Feeder media weight :
  1-sided scanning: 38 to 128 gsm
  2-sided scanning: 50 to 128 gsm
• Supported Media Sizes
  Platen: max. scanning size: 297.0 x 431.8 mm
  A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6R
  Custom size: 48.0 x 85.0 mm to 304.8 x 431.8 mm
• Scan Method
  Push Scan, Pull Scan, Scan to Network, Scan to memory media (USB Memory Key), Scan to Mobile Devices, Scan to cloud-based services (uniFLOW Online)
• Scan Speed
  Single Pass DADF-F1 (for imageFORCE 4045):
  1-sided Scanning: 80/80 (300 x 300 dpi, send)
  2-sided Scanning: 120/120 (300 x 300 dpi, send)

  Single Pass DADF-G1 (for imageFORCE 4030/4025):
  1-sided Scanning: 35/35 (300 x 300 dpi, send)
  2-sided Scanning: 70/70 (300 x 300 dpi, send)

Send Specifications

• Destination
  Standard: E-mail/Internet FAX (SMTP*), SMB, FTP, SFTP, FTPS, WebDAV
  Optional: Super G3 FAX

  * Available OAuth 2.0 authentication method on Microsoft Exchange Online and Google Workspace
• Address Book / Speed Dials
  LDAP (2,000)/ Local (1,600) /Speed dial (200)
• Communication Protocol
  File: FTP (TCP/IP), SFTP (TCP/IP), FTPS (TCP/IP), SMB3.1.1 (TCP/IP), WebDAV
  E-mail/iFax: SMTP(send), POP3(receive)
• File Format
  Standard: TIFF (MMR), JPEG*, PDF (Compact, Searchable, PDF/A-1a, A-1b, PDF/A-2a,PDF/A-2b,PDF/A-2u, PDF/A-3a,PDF/A-3b,PDF/A-3u, Trace&Smooth, Encrypted), XPS (Compact, Searchable), PDF/XPS (Device Signature, User Signature), Office Open XML (PowerPoint, Word)
  Option: PDF(Trace & Smooth), PDF/XPS (User Signature)

  * Single-Page only.
• Universal Send Features
  Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Originals, Dropout Color

Fax Specifications

• Maximum Number of Connection Lines
  1
• Modem Speed
  Super G3: 33.6 kbps
  G3: 14.4 kbps
• Compression Method
  MH, MR, MMR, JBIG
• Resolution (dpi)
  400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal)
• Sending/Receiving Size
  Sending: A3, A4, A4R, A5*1, A5R*1, B4, B5*2, B5R*1
  Receiving: A3, A4, A4R, A5, A5R, B4, B5, B5R

  *1 Sent as A4
  *2 Sent as B4 short
• Fax Memory
  Up to 30,000 pages (2,000 jobs)
• Speed Dials
  Max. 200
• Group Dials/Destinations
  Max. 199 dials
• Sequential Broadcast
  Max. 256 addresses
